Horizontal vs Vertical GNSS Accuracy: Why Elevation Is Less Precise

Have you noticed that your GNSS-based elevation measurements often seem less reliable than your horizontal position? This is a common question among surveyors, engineers, and outdoor enthusiasts who rely on GNSS or GPS systems. While horizontal positioning is usually precise, vertical (height) measurements face unique challenges. Let’s explore why.

1. How GNSS Determines Elevation

To calculate elevation, GNSS first determines the ellipsoid height, which is the height relative to the reference ellipsoid. However, this ellipsoid height is not the same as the actual elevation, which is defined relative to the geoid—the true mean sea level. To convert the ellipsoid height into a true height, GNSS systems use a local geoid model. The GNSS elevation is determined by subtracting the geoid height (the height difference between the ellipsoid and the geoid) from the ellipsoid height:

GNSS Elevation = Ellipsoid Height - Geoid height

The challenge arises because geoid models are approximations, and they may not perfectly represent the true surface of the Earth's gravitational field. As a result, GNSS-based elevation measurements can be affected by inaccuracies in the geoid model and local variations in the gravity field.

2. Why Vertical Accuracy Is More Challenging

GNSS works by calculating the distances between your receiver and multiple satellites orbiting the Earth. This process provides highly accurate horizontal positioning (latitude and longitude) but often struggles with vertical (elevation) accuracy. Here's why:

2.1 Satellite Geometry

GNSS satellites are located above the Earth’s surface, which means they’re spread out in the upper hemisphere of the sky. This results in strong horizontal geometry (latitude and longitude), as satellites are visible from all directions around the receiver. However, the vertical geometry is weak since satellites are only positioned above the receiver.

This lack of satellites beneath the receiver creates a challenge in minimizing errors in the vertical direction. When there are fewer satellites positioned below, even small measurement errors in elevation can get amplified. Horizontal errors, on the other hand, can often be corrected more easily.

The difference in geometry is often quantified by the Vertical Dilution of Precision (VDOP), which tends to be higher than the Horizontal Dilution of Precision (HDOP), indicating that elevation measurements are typically less accurate than horizontal ones.

2.2 Atmospheric Delays

GNSS signals travel through the Earth's atmosphere before reaching the receiver. The length of this path—especially through the troposphere (the lower layer of the atmosphere)—can affect the accuracy of height calculations. Atmospheric conditions, such as temperature and moisture, cause signal delays that distort vertical measurements more than horizontal ones.

In Real-Time Kinematic (RTK) differential positioning, any atmospheric discrepancies between the base station and the rover can introduce residual errors that directly impact height accuracy.

2.3 Multipath Effects

Multipath occurs when GNSS signals reflect off surfaces such as buildings, water bodies, or the ground before they reach the receiver. This is especially problematic when the signals have a low elevation angle, as they are more prone to disturbances from these reflections.
Multipath effects on vertical positioning are more pronounced than on horizontal positioning, which makes elevation measurements particularly susceptible to interference and errors.

Conclusion

Vertical GNSS positioning is inherently less accurate than horizontal due to weaker satellite geometry, atmospheric delays, multipath effects, and geoid model limitations. Understanding these factors helps interpret GNSS results correctly and choose appropriate solutions.

For professional applications—surveying, construction, autonomous vehicles, or precision agriculture—high vertical accuracy is essential. Modern GNSS solutions, like Qtalis K803 and K902 modules, integrate multi-constellation, multi-frequency, and advanced signal processing to improve both horizontal and vertical reliability in real-world environments.
