| Signal tracking | Channels: 335 GPS: L1 BeiDou: B1 GLONASS: L1 Galileo: E1 QZSS: L1C SBAS: WAAS, EGNOS, MSAS, GAGAN |
| Cold Start | < 50s |
| Warm Start | <45 s |
| Signal reacquisition | < 3s |
| RTK Initialization time | <10 s |
| Initialization Reliability | 99.9% |
| Post Processing | 2.5 mm + 1 ppm Horizontal 5 mm + 1 ppm Vertical |
| Single Baseline RTK | 8 mm + 1 ppm Horizontal 15 mm + 1 ppm Vertical |
| DGPS | <0.4m RMS |
| SBAS | 1m 3D RMS |
| Standalone | 1.5m 3D RMS |
| Size (L x W x H) | 137 mm × 72 mm × 50.4 mm |
| Weight | <0.35 kg (with 1 battery inside) |
| Power consumption | 1.6 W |
| Operating temperature | -20 °C to +60 °C |
| Storage temperature | -30 °C to +70 °C |
| Waterproof | IP65 |
| Shock and vibration | Survive a 1.5m nature drop onto concrete |
| Battery capacity | 3400 mAh |
| Working time | Over 16 h continuous work |
| Charging time | 2.5 h |
| Bluetooth® 4.0 | Compatible with Android™ and Windows™ mobile OS |
| Support Ntrip protocol (based on software) | |
| 1 serial port (9 pin Fischer), 1 Fischer connector | |
| 3 LEDs (indicating Power, Satellite Tracking and Bluetooth) |
Note:
Specifications subject to change without notice.
