Application
| Satellites tracking | GPS: L1C/A, L2C, L2P, L5, L1C BeiDou BDS-2: B1I, B2I, B3I BDS-3: B1I, B3I, B1C, B2a, B2b GLONASS: G1, G2, G3 Galileo: E1, E5a, E5b, E6c, E5 AltBOC QZSS: L1C/A, L2C, L5, L1C SBAS: L1C/A, L5 NavIC: L5 L-Band |
| Post Processing | 2.5 mm + 1 ppm Horizontal 5 mm + 1 ppm Vertical |
| Single Baseline RTK | 8 mm + 1 ppm Horizontal 15 mm + 1 ppm Vertical |
| DGPS | <0.4 m RMS |
| SBAS | 1 m 3D RMS |
| Standalone | 1.5m 3D RMS |
| Cold start | <20 s |
| Hot start | <10 s |
| RTK Initialization time | <10 s |
| Signal reacquisition | <1 s |
| Initialization reliability | >99.9% |
| Velocity accuracy | ≤ 0.02 m/s |
| Acceleration | 4 g |
| Overload | 15 g |
| Time accuracy | 20 ns |
| Size (L x W x H) | 73.5 mm × 100 mm × 22 mm |
| Weight | 82.5g |
| Hardware interface | 1.6 pin,2.5mm |
| Power consumption | 1.5 W |
| Input voltage | +5-12V DC |
| Operating temperature | -40 °C to + 85 °C |
| Storage temperature | -55 °C to + 95 °C |
| LNA Power External | +3.3V ~ +5V ± 5%VDC @ 0-100mA |
| LNA Gain | 20 ~ 40dB (suggested) |
| Impedance Matching | Wiring 50 Ω impedance matching |
| LVTTL ports | 1XRS232, 3XLVCMOS |
| BT | 1 |
| Event Markers input | 2 |
| Pulse Per Second (PPS) output | 1 |
| GPIO | 2 |
| Correction data I/O | RTCM 2.X, 3.X, CMR(GPS only), CMR+(GPS only) |
| Position data output | - ASCII: NMEA-0183 GGA, GSA, GSV, RMC, HDT, VHD, ZDA, VTG, GST, GLL; PTNL, PJK; PTNL, AVR; PTNL, GGK - ComNav Binary - BINEX Data: 0x00, 0x01-01, 0x01-02, 0x01-05, 0x7d-00, 0x7e-00, 0x7f-05 - Position data output rate: 1 Hz, 2 Hz, 5 Hz, 10 Hz, 20Hz |
