| Channels | 1590 |
| Signal Tracking | GPS: L1C/A, L2P, L2C, L5, L1C BeiDou: B1I, B2I, B3I, B1C, B2a, B2b GLONASS: L1, L2, L3 Galileo: E1, E5b, E5a, E6c, E5 AItBOC QZSS: L1C, L2, L5, L1C/A SBAS: L1C/A IRNSS: L5 |
| Single Baseline RTK | 8 mm +1 ppm Horizontal 15 mm+1 ppm Vertical |
| SBAS | 0.5m Horizontal 0.8m Vertical |
| Standalone | 1.5m 3D RMS |
| Post Processing | 2.5 mm +1 ppm Horizontal 5 mm+1ppm Vertical |
| PPP (B2b & HAS) | 20cm Horizontal |
| CPU | 8-core processor 2.0GHz |
| Operating System | Android 11 |
| ROM | 64GB (128GB optional) |
| RAM | 4GB (6GB optional) |
| Extension | 1 Micro SD card slot up to 128G |
| Rear Camera | 13M |
| Front Camera | 5M |
| Battery | 6600mAh built-in battery |
| Size (W x L x H) | 165.5*81.6*29.1mm |
| LCD | 6"HD screen 2160*1080 resolution |
| Touch Screen | Capacitive multi-touch, 5 points |
| Flash Light | Y |
| Microphone | Y |
| Speaker | Front dual stereo 90dB±3dB (at 10cm) |
| Weight | 310g |
| Charging | Quick Charge |
| Keypad | 4*Doer 1*HOME 1*Return, 1*Position |
| Work Temperature | -20°C~55°C |
| Storage Temperature | -30°C~70°C |
| Waterproof & Dustproof | IP67 |
| Drop Test | Survive from a 1.2m drop |
| Electrostatic Protection | ±15kv air discharge ±8kv contact discharge |
| Humidity | 95% non-condensing |
| WIFI | IEEE 802.11 a/b/g/n/ac 2.4GHz/5GHz |
| SIM Card | 2 Nano-SIM Card slots Dual SIM & Dual Standby |
| Network | FDD-LTE B1/B3/B5/B7/B8 TDD-4TE 838/B39/B40/B41 TDSCDMA B34/B39 WCDMA B1/B2/B5/B8 GSM B2/B3/B5/B8 CDMA 1x/CDMA2000 BCO/BC1 |
| Bluetooth | BT 5.0 BLE |
| USB | Type C, support OTG |
| External Interface | USB, OTG |
| G Sensor | Y |
| Magnetometer | Y |
| Light Sensing Sensors | Y |
