T80 GNSS Receiver

High-Precision GNSS for Connected Field Applications

T80 GNSS Receiver

$799.00 USD
$799.00 USD
Sale Sold out
Shipping calculated at checkout.
ⓘ

Volume Pricing & OEM Support

Bulk pricing, OEM customization, and system integration.

Request a Quote
  • Global Shipping
  • 1-Year Warranty
  • Engineering Support

The T80 GNSS Receiver combines multi-frequency, full-constellation GNSS with integrated connectivity and tilt measurement for reliable positioning across diverse field applications. Featuring a built-in color display, 4G connectivity, and support for flexible correction services, T80 streamlines field workflows with convenient configuration and seamless data integration. Its rugged magnesium-aluminum alloy housing and IP68-rated protection ensure dependable performance in demanding environments.

Key Features

  • Full-Constellation, Multi-Frequency GNSS with 1688 channels
  • Optional PPP-B2b and HAS Support
  • Integrated Connectivity: 4G, Bluetooth, Wi-Fi, and NFC
  • Tilt Measurement for efficient point collection
  • Rugged IP68 Protection with a built-in color display
View full details

 Technical Specifications

Signal trackingChannels: 1688
GPS: L1C/A, L2P, L1C, L2C, L5
BDS: B1I, B3I, B1C, B2a, B2b
GLONASS: G1C, G1P, G2C, G2P
Galileo: E1, E5b, E5a, E5AltBOC, E6
QZSS: L1C/A, L2C, L5, L1C
NavIC: L5
SBAS: L1C/A, L5C
PPP: B2b & HAS²
Cold Start< 45s
Hot Start< 15s
Signal reacquisition≤ 1s
RTK Initialization time<5 s
Initialization Reliability>99.99%
Static¹H: ±(2.5 mm + 0.5 ppm)
V: ±(5 mm + 0.5 ppm)
RTK¹H: ±(8 mm + 1 ppm)
V: ±(15 mm + 1 ppm)
RTDH: ±0.25 m; V: ±0.50 m
SBAS<1 m (3D RMS)
Smoothed standaloneH: ±1 m; V: ±1.5 m
Tilt measurement≤2 cm at tilt ≤30° (1σ)
Dimensions Ø133.5 × 66 mm
Weight ≤850 g
Display Color display for status and mode settings
KeysPower key and function key
Pole mount5/8-inch UNC female thread
UHF antenna 50 Ω, TNC female connector
Power consumption1.8W³
Input voltage5 V / 9 V ±5% DC
Li-ion battery capacity5000 mAh
Working time16 h
Charging: ≤5 h; QC2.0 fast charging
Charging interfaceUSB Type-C
Internal storage4 GB
Working temperature-20 °C to +65 °C
Storage temperature-40 °C to +85 °C
Humidity100% non-condensing
Water & dust protectionIP68
Drop resistance2 m free fall
Interface USB Type-C and 7-pin LEMO
Cellular Built-in 4G modem; SIM card interface
Network correctionsNTRIP over mobile network
UHF data linkIntegrated transmitter and receiver
Transmit power: 0.5 W / 1 W / 2 W selectable
Receive sensitivity: Down to -115 dBm
Air baud rate: 5 selectable levels
Protocols: Transparent / TT450S / South / Mac / SNLonglink
Bluetooth BT2.1+EDR / 3.0 / 4.1 / 4.2 LE
Wi-FiWeb Server support
NFCSupported
Correction dataRTCM 2.x, 3.0 and 3.2 (MSM4-MSM7)
Position dataNMEA-0183 (GPGGA, GPGSV, GPGSA, GPRMC, GPVTG, GPZDA)
Binary dataCNB (SinoGNSS proprietary)
Note:
1. ¹ ppm is relative to baseline length. H = horizontal; V = vertical.
2. ² PPP service is optional. ³ Power consumption increases during internal UHF transmission
